Structure
and reason: the blow air which
carried dust will pass through the pipe to the collect cup. The high speed air
in the collect can will follow the whirlpool to spin, and centrifugal force
will separate the solid according to their size. As for the air blow, it will
blow out to to the pipe, the windmill is also used.
Structure and reason: the air with lots of powder will pass thought
the fall down room. We will do the first filter and then collect the duct with
filter bag. The duct will attach to bag pipe area and finally become to dust
cake (something shaped like a cake) . At the end, we will use high pressure air
to blow the dust cake, and let them fall
down to the dust collect cup and send out and collect with the fan
delivery device.
Usage: 1.for all kinds of powders, like woods. 2.end
recycle of air delivery device 3.max air change of powder or smoke area
Special: 1. in the instantly counterclockwise auto
wash, the loss is very small in the stable wind and pressure. 2. device
accessories are less and filter bag is easy to attach 3.high efficiency to
collect dust 4.with the pressure air blow, dust will fall automatically,
therefore the machine could be used 24 hours all day, no need to turn down at
all.
suitable: asphalt blend, furnace, wood, chemical,
casting, medicament, IT, powder collect and recycling.
